1A1 Series Sauce Filling Valve With Internal Sealing
Pipeline pressure: 0-7 bar (0-102 psi)
Control pressure: > 3bar (44psi)
Valve body material: CF8M
Sealing material: PTFE
-
1A2 Series Internal Sealing Filling Valve
Pipeline pressure: 0-7bar (0-102psi)
Control pressure: 3-4.5bar (44-65psi)
Body material: CF8M
Medium temperature: -10 ℃-+ 120 ℃
Ambient temperature: -10 ℃-+ 80 ℃
*Customized services can be provided
-
200 Series Pneumatic Shuttle Valve
Fluid Pressure: Max 16bar (232psi)
Control Pressure: 3-8bar (43.5-116psi)
Body Material: CF8M/CF8
-
204 Series Flange Shuttle Valve
Fluid Pressure: Forward: Max 1.6MPa (232psi), Reverse: Max 1.2MPa (174psi)
Control Pressure: 0.3-0.5MPa (43.5-72.5psi)
Body Material: CF8
Medium Temperature: -20 ° C — +130 ° C
Ambient Temperature: -20 ° C — +80 ° C
-
300 Series Pneumatic Butterfly Valve
Pipeline pressure: Max 16bar (232psi)
Control pressure: 3-8bar (43.5-116psi)
Applicable medium: EPDM is suitable for hot water and steam.
Not suitable for greases, fuels, etc.
Medium temperature: -10 ° C - +130 ° C
-
412 Series 1-PC Flanged ball valve with Mounting Pad
Nominal Pressure: PN16/25/40 (1/2"~2")；PN16(2-1/2"~4")
Medium Temperature: -10 ° C - +120 ° C (PTFE common type)
Sphere Material: CF8 (304), CF8M (316)
-
421 series 2-PC Ball Valve (F/F)
Nominal Pressure: PN63
Applicable Temperature: -10 °C - +120 °C (PTFE common type)
Body and Bonnet: CF8/CF8M
Stem: CF8 (304), CF8M (316)
-
422 Series 2-PC Ball Valve (F/M)
Nominal Pressure: PN63
Medium Temperature: -10 °C - +120 °C (PTFE common type)
Body and Bonnet: CF8/CF8M
Sphere material: CF8 (304), CF8M (316)
-
431 Series 3-PC Threaded Ball Valve
Nominal Pressure: PN63
Applicable Temperature: -10 ° C - +120 ° C (PTFE common type)
Body and Bonnet: CF8/CF8M
Stem: CF8(304), CF8M(316)
Seal material: PTFE
